Located in the heart of Amman, Jordan, Yazan Steel has built a strong reputation for providing robust and reliable industrial materials. We specialize in sourcing and supplying high-performance alloy steel tubing, with our Alloy Steel T9 standing as a prime example of our commitment to quality. This particular grade is engineered to tackle demanding environments, making it an ideal solution for industries across the region that require materials capable of withstanding intense heat and pressure, all backed by our dependable local service.
The composition of Alloy Steel T9 tubing is precisely balanced for resilience, featuring chromium and molybdenum as its key strengthening elements. This specific blend gives the tubing its notable mechanical properties, including an exceptional tensile strength and strong resistance to creep. These characteristics allow it to maintain its structural integrity even when subjected to the high temperatures and constant pressures that would cause lesser materials to fail, ensuring long-lasting performance in critical applications.
| ASTM A213 T9 Specification & Standard | ASTM A213 T9, ASME SA213 T9 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T9 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T9 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 Grade T9 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| SA213 Grade T9 Pipe Thickness | 3-12mm |
| ASTM A213 Grade T9 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| Craft | Cold rolled and Cold drawn |
| SA213 Grade T9 Tube Type | Seamless / ERW / Welded / Fabricated |
| A213 Grade T9 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| T9 Steel Grade Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| SA213 T9 Steel Tube Length | Standard Double & In Cut length also. |
| T9 Steel Grade Tube End | Plain End, Beveled End, Treaded |
| SA213 Grade T9 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| SA213 T9 Steel Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T9 Composition |
0.15 max |
0.30~0.60 |
0.025 |
0.025 |
0.25-1.0 |
0.90~1.10 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| T9 | 415 min | 205 min | 30 min | 179 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a trusted manufacturer and supplier of premium Alloy Steel T5 Tubing in Amman, Jordan. We specialize in high-quality steel materials and offer a diverse range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to timely delivery and outstanding customer service, we use only the finest raw materials to ensure exceptional performance in demanding industrial applications. Contact us today for all your Alloy Steel T5 Tubing needs!
The unique strength of Alloy Steel T9 tubing makes it indispensable in several high-stakes industries. You will commonly find it forming the backbone of power generation systems, particularly in superheater and reheater tubes within boilers. It’s also essential in refineries and petrochemical plants for constructing process piping and heat exchangers. Essentially, wherever there is a need to safely and efficiently contain hot gases, steam, or corrosive process fluids under significant pressure, this tubing provides a trusted and durable solution.
Yazan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Amman, Jordan.
