Yazan Steel is a trusted manufacturer and supplier located in Amman, Jordan, providing high-quality structural steel products tailored for construction and engineering needs. They specialize in IS 2062 E250 Sheets and Plates, a popular structural steel grade defined by Indian Standard IS 2062. This grade is recognized for its balanced strength, excellent weldability, and cost-effectiveness, making it ideal for various structural and fabrication tasks. Yazan Steel is committed to maintaining rigorous quality control, ensuring dimensional accuracy, and adhering to standards to support both infrastructure and industrial projects.
IS 2062 E250 sheets and plates are crafted from carbon-manganese steel, featuring carefully controlled amounts of carbon, manganese, silicon, sulfur, and phosphorus. This grade boasts a minimum yield strength of around 250 MPa, along with moderate tensile strength and good elongation properties. These characteristics guarantee outstanding weldability, formability, and machinability. The material is known for its reliable toughness and stability under typical structural loads, making it a great choice for everyday fabrication and construction tasks.
| Product Name | Fe 410WB Plates- IS 2062 E250 |
|---|---|
| Standard | IS 2062 |
| Equivalents | 43 D, St 44-3U, E28-4, S275J2G3 |
| Thickness | 6MM to 300MM |
| Width | 1500mm to 4050mm |
| Length | 3000mm to 15000mm |
| Certification | Mill Test Reports Available as per EN 10204 3.1 |
| Element | C.E. Value | Mn | C | S | Si | P | Nb+V+Ti |
| E-250 Gr-B | 0.41 max | 1.50 max | 0.22 max | 0.045 max | 0.40 max | 0.045 max | – |
| E-250 Gr-A | 0.42 max | 1.50 max | 0.23 max | 0.050 max | 0.40 max | 0.050 max | – |
| E-250 Gr-C | 0.39 max | 1.50 max | 0.20 max | 0.040 max | 0.40 max | 0.040 max | – |
| Grade | Tensile | Min Yield | Elongation | Thickness(mm) | Min Impact Energy | |
| Fe 410WB | 410Mpa | Min 250Mpa | 23% | ＜20mm | 27J | 0 |
| 410Mpa | Min 240Mpa | 23% | 20mm-40mm | 27J | 0 | |
| 410Mpa | Min 230Mpa | 23% | ＞40mm | 27J | 0 | |
| EN10025(93) | EN10025(90) | JIS3101 | BS4360 | DIN 17100 | NFA 35-501 |
| S275J2G3 | – | – | 43 D | St 44-3U | E28-4 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
IS 2062 E250 sheets and plates find extensive use in general construction and engineering projects. Common applications include building structures, beams, columns, base plates, industrial sheds, and platforms. They are also utilized in the fabrication of storage tanks, containers, machinery bases, automotive parts, and agricultural equipment. Thanks to their affordable pricing and ease of fabrication, these sheets and plates are often the go-to choice for non-critical and medium-load structural applications across various infrastructure and industrial sectors.
Yazan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Amman, Jordan.
