Yazan Steel, a well-respected manufacturer and supplier located in Amman, Jordan, is dedicated to delivering top-notch steel products that adhere to both international and regional standards. One of their standout offerings is the Carbon Steel DIN 17172 pipe, designed for exceptional strength, durability, and performance in various industrial applications. By employing cutting-edge manufacturing techniques and rigorous quality control measures, Yazan Steel guarantees that each pipe provides precision, consistency, and long-lasting reliability. With a strong focus on timely delivery, competitive pricing, and outstanding customer support, the company has built a solid reputation as a trusted supplier for engineers, contractors, and industries in need of reliable steel solutions.
The Carbon Steel DIN 17172 Pipe consists mainly of carbon and small proportions of manganese, silicon, and other trace elements. This makes the pipes very strong, resistant to corrosion, and durable. Their mechanical properties are tensile strength of 400-550 MPa, yield strength of 250-355 MPa, and elongation of 22-28%. These pipes have good weldability, formability, and impact resistance, making them ideal for demanding industrial applications, such as pipelines, structural components, and machinery. Their resistance to high-pressure environments enhances their performance and life in service.
| Standards | DIN 17172 StE 360.7 Pipe |
|---|---|
| Welded Pipe Size | 5.0 mm – 1219.2 mm |
| Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| EFW Pipe size | 5.0 mm – 1219.2 mm |
| Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| We can also cut, thread, and groove Tubes to meet your specifications | |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| max 0.22 | max 0.55 | 0.90 – 1.50 | 0.04 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 630 | – | – | 20 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
The Carbon Steel DIN 17172 pipe is a low- to medium-carbon alloy, featuring carefully regulated levels of carbon, manganese, silicon, phosphorus, and sulfur. This specific composition strikes a perfect balance between tensile strength, toughness, and excellent machinability. Mechanically, it offers dependable wear resistance, moderate hardness, and the capability to perform well under varying stress conditions. Additionally, DIN 17172 pipes can undergo heat treatment processes like normalizing or quenching and tempering to further enhance their mechanical properties and structural stability. These traits make the material an ideal choice for applications that demand strength, durability, and precise performance.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | #ERROR! | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | #ERROR! | ± 0.30 mm± 0.35 mm± 0.40 mm |
Thanks to its unique combination of strength, reliability, and versatility, the Carbon Steel DIN 17172 pipe is utilized across a wide range of industrial sectors. It’s commonly found in mechanical engineering, construction, pressure piping, and equipment manufacturing. This pipe is perfect for fluid transport systems, structural frameworks, machinery components, and other applications that require consistent performance under moderate loads and pressures. Its excellent formability and weldability also make it a go-to option for fabricated parts and custom-engineered components. In summary, DIN 17172 pipes offer a cost-effective, durable, and high-performance solution for industries that demand quality and reliability.
