Yazan Steel is a trusted manufacturer and supplier located in Amman, Jordan, specializing in precision alloy steel products tailored for advanced engineering needs. They provide Alloy Steel Grade 5 Foils, crafted with meticulous attention to thickness, surface finish, and mechanical consistency. Known for their high strength, durability, and precise dimensions, Grade 5 alloy steel foils are ideal for specialized industrial applications. Yazan Steel adheres to rigorous quality standards to guarantee dependable performance, uniform properties, and compliance with international specifications for critical uses.
Alloy Steel Grade 5 foils are generally made from medium-carbon alloy steel, which contains carefully controlled levels of carbon, manganese, and other alloying elements to boost strength and hardness. This material boasts impressive tensile strength, solid yield strength, and moderate ductility, even in its thin form. These foils are known for their excellent fatigue resistance, dimensional stability, and favorable response to heat treatment. Their mechanical characteristics make them perfect for precision components where strength and reliability in thin sections are crucial.
| Specifications | : | ASTM A387 / ASME SA387 |
| Thickness | : | 1mm-300mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, 4050mm etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, 12000mm, 15000mm etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| Alloy Steel Gr 5 | 0.15 max | 0.30-0.60 | 0.5 max | 0.035 max | 0.030 max | 4.0 – 6.0 | 0.45 – 0.65 | – | – |
| Tensile (MPa) | Yield (MPa) | Elongation (50mm) | Elongation (200mm) | Reduction of Area |
| 415 – 585 | 205 min | 18% min | – | 40% min |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Alloy Steel Grade 5 foils find extensive use in precision engineering and various industrial applications. They are commonly utilized as shims, spacers, washers, springs, gaskets, and laminated components. Additionally, they play a role in automotive assemblies, aerospace sub-components, electrical insulation layers, and parts for high-performance machinery. Thanks to their impressive strength-to-thickness ratio and consistent quality, these foils are the go-to choice for applications that demand tight tolerances, durability, and reliable performance under mechanical stress and vibration.
Yazan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Amman, Jordan.
