Yazan Steel, located in Amman, Jordan, is a reliable manufacturer and supplier known for delivering cutting-edge steel solutions tailored for tough structural and engineering needs. They offer High Strength Steel Sheets and Plates that are designed to provide exceptional load-bearing capacity, durability, and structural efficiency, far surpassing traditional carbon steels. Each product is crafted under rigorous quality control standards to guarantee consistent mechanical properties and precise dimensions. Yazan Steel plays a vital role in supporting sectors like infrastructure, construction, automotive, and heavy engineering with high-strength steel that promises dependable long-term performance.
High strength steel sheets and plates are made from low- to medium-carbon steel, incorporating carefully controlled alloying elements such as manganese, silicon, and micro-alloys like niobium or vanadium. This specific blend boosts yield and tensile strength while ensuring good toughness and weldability. The material boasts a high strength-to-weight ratio, impressive elongation, excellent fatigue resistance, and stable performance under both static and dynamic loads. These characteristics make it ideal for efficient fabrication and maintaining structural integrity in demanding applications.
| Item | High Strength Steel Plate |
| Material | 450 Yield ,A36 ,A516 ,A572 , A573 ,A588 , A606 ,A709 Grade 50 ,A871 Grade 65 ,AASHTO M270 ,CSA G40.21 ,Hot Rolled Steel Plate,PVQ A283 ,PVQ A285 ,SAILMA Grade 350 HI , SAILMA Grade 450 HI |
| Thickness | 6-300mm |
| Width | 900-4100mm |
| Length | 3000-25000mm |
| Type | Steel Plate |
| S | Cr | P | Al | C | Ni | Si | Mo | Mn |
|---|---|---|---|---|---|---|---|---|
| 0.005 max | 1.50 max | 0.0.20 max | 0.015 max | 0.20 max | 2.0 max | 0.80 max | 0.70 max | 1.70 max |
| Thickness milimeter | Rm MPa | Re MPa | A % |
|---|---|---|---|
| < 50 | 770 – 940 | 690 | 14 |
| > 50 ? 100 | 760 – 930 | 650 | 14 |
| > 100 | 710 – 900 | 630 | 14 |
| grade | DENSITY | (MPA)YIELD STRENGTH |
|---|---|---|
| water quenched 480 °C (900 °F), temper 855 °C (1570 °F) AISI 4130 | 7.85 G/CM³ | 951 |
| clear cast sheet (PMMA), Acrylic | 1.16 G/CM³ | 72 |
| Steel, high strength alloy ASTM A514 | 7.8 G/CM³ | 690 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
|
Grade
|
Nominal Thickness t (mm)
|
||
|
3 ≤ t ≤ 50
|
50 < t ≤ 100
|
100 < t ≤ 150
|
|
|
Minimum yield strength ReH, MPa
|
|||
|
S460Q
|
460
|
440
|
400
|
|
S500Q
|
500
|
480
|
440
|
|
S550Q
|
550
|
530
|
490
|
|
S620Q
|
620
|
580
|
560
|
|
S690Q
|
690
|
650
|
630
|
|
S890Q
|
890
|
830
|
|
|
S960Q
|
960
|
|
|
|
|
Tensile strength Rm, MPa
|
||
|
S460Q
|
550-720
|
500-670
|
|
|
S500Q
|
590-770
|
540-720
|
|
|
S550Q
|
640-820
|
590-770
|
|
|
S620Q
|
700-890
|
650-830
|
|
|
S690Q
|
770-940
|
760-930
|
710-900
|
|
S890Q
|
940-1100
|
880-1100
|
|
|
S960Q
|
980-1150
|
|
|
|
Quality
|
Test Temperature °C
|
|||
|
-20
|
-40
|
-50
|
-60
|
|
|
M
|
40J
|
|
|
|
|
ML
|
|
|
27J
|
|
|
Q
|
30J
|
|
|
|
|
QL
|
|
30J
|
|
|
|
QL1
|
|
|
|
30J
|
High strength steel sheets and plates find extensive use in projects that demand high structural efficiency and lighter weight. Common applications include bridges, skyscrapers, cranes, pressure vessels, and heavy machinery. They are also utilized in automotive chassis, truck frames, trailers, rail wagons, and various industrial fabrication tasks. Thanks to their remarkable durability and strength, these steels are the go-to choice for infrastructure and engineering projects that face high stress, vibration, and long-term service conditions.
Yazan Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Amman, Jordan.
